Features
- Small exposed cover makes the unit virtually invisible for more attractive landscapes
- Constructed of durable materials including corrosion resistant stainless steel, assuring long product life even in high pressure or surge conditions
- Pressure-activated wiper seal prevents excessive flow-by and water waste and keeps debris from entering upon retraction
- Two-piece ratchet mechanism allows easy nozzle pattern alignment and provides added durability
- Three-year trade warranty
Specs
- Pressure: 15 to 70 psi (1.0 to 4.8 bar)
- Optimum pressure: 30 psi (2.1 bar)
- Adjustable nozzle arc range: 0° – 360°
- Flow-by: 0 at 10 psi (0.75 bar) or greater; 0.20 gpm (0.04 m³/h; 0.60 l/m) otherwise
Dimensions
- Dimensions: 1/2″ (15/21) NPT female threaded inlet
- Body Height: 5 7/8″ (14.9 cm)
- Exposed Surface Diameter: 1 1/4″ (3.2 cm)
Model Comparison
Base Model
- US400: 4″ pop-up height (10.2cm)
Models with High-Efficiency Spray Nozzles – Pre-Attached
- US408HE: 4″ pop-up height (10.2cm) with HE-VAN-08 attached
- US410HE: 4″ pop-up height (10.2cm) with HE-VAN-10 attached
- US412HE: 4″ pop-up height (10.2cm) with HE-VAN-12 attached
- US415HE: 4″ pop-up height (10.2cm) with HE-VAN-15 attached
Models with Spray Nozzles – Pre-Attached
- US410: 4″ pop-up height (10.2cm) with VAN-10 attached
- US412: 4″ pop-up height (10.2cm) with VAN-12 attached
- US415: 4″ pop-up height (10.2cm) with VAN-15 attached
- US418: 4″ pop-up height (10.2cm) with VAN-18 attached
Accessories
- USSAM: Field installed Seal-A-Matic (SAM) Check Valve
