Features
- Optional locking cover on models 33-DLRC, 44-LRC, 5-LRC, 33-DNP, 44-NP, and 5-NP (use 2049 key to unlock). Metal cover on model 7 only
- One-piece body design (models 3-RC, 5-RC and 7)
- Two-piece body design for easy servicing (models 33-DRC, 44-LRC, 44-RC, 33-DNP, and 44-NP)
- Strong corrosion-resistant stainless steel spring prevents leakage
- Thermoplastic cover for durability
- 33-DNP, 44-NP, and 5-NP covers marked with “Do Not Drink!” warnings in English and Spanish
- Three-year trade warranty
Specs
- Pressure: 5 to 125 psi (0.35 to 8.63 bar)
- Flow: 10 to 125 gpm (2.27 to 28.38 m3⁄h; 37.8 to 473 l/m)
- 33-DNP, 44-NP, and 5-NP flow: 10 to 70 gpm (2.27 to 15.89 m3⁄h; 37.8 to 265 l/m)
Dimensions
- 3-RC: Height 4¼” (10.8 cm)
- 33-DRC: Height 4 3⁄8″ (11.1 cm)
- 33-DLRC: Height 4 5⁄8″ (11.7 cm)
- 44-RC: Height 6″ (15.2 cm)
- 44-LRC: Height 6″ (15.2 cm)
- 5-RC: Height 5½” (14.0 cm)
- 5-LRC: Height 5½” (14.0 cm)
- 7: Height 5¾” (14.6 cm)
- 33-DNP: Height 4 3/8″ (11.1 cm)
- 44-NP: Height 6″ (15/2 cm)
- 5-NP: Height 5½” (14.0 cm)
Model Comparison
- 3-RC: ¾” NPT Rubber Cover, 1-Piece Body
- 33-DRC: ¾” NPT Double Track Key Lug, Rubber Cover, 2-Piece Body
- 33-DLRC: ¾” NPT Double Track Key Lug, Locking Rubber Cover, 2-Piece Body
- 44-RC: 1″ NPT Rubber Cover, 2-Piece Body
- 44-LRC: 1″ NPT Locking Rubber Cover, 2-Piece Body
- 5-RC: 1″ NPT Rubber Cover, 1-Piece Body
- 5-RC-BSP: 1″ BSP Rubber Cover, 1-Piece Body, BSP threaded
- 5-LRC-BSP: 1″ BSP Locking Rubber Cover, 1-Piece Body, BSP threaded
- 7: 1½” NPT Metal Cover, 1-Piece Body
Non-Potable
- 33-DNP: ¾” NPT Non-potable, Purple Locking Rubber Cover, 2-Piece Body
- 44-NP: 1″ NPT Non-potable, Purple Locking Rubber Cover, 2-Piece Body
- 5-NP: 1″ NPT Non-potable, Purple Locking Rubber Cover, 1-Piece Body
International
- 33DK: Valve key ¾” male and ½” female threads
- 5LRC: 1” BSP female threaded inlet wit
