Features
- Upgradeable for WiFi-based remote monitoring and control via iOS and Android mobile devices (with LNK2 WiFi Module sold separately)
- Internet-based weather information can be used to make daily adjustments to the irrigation schedule, saving up to 30% in water (with LNK2 WiFi Module sold separately)
- 4, 6, 8, and 12 station models to meet small or large residential irrigation needs
- Set Permanent Days Off per program to ensure watering never occurs on days when maintenance crews are on site (for Odd/Even/ Cyclic schedules)
- Easy to install indoors or outdoors
- Quick programming in just 3 steps for ease of setup
- 3 available programs with up to 4 start times for each program to meet the needs of varied landscapes
- One-touch manual watering capability for ease of use
- Large back-lit LCD display for improved visibility in low-light and direct sun conditions
- Contractor Default™ allows you to easily save and restore your custom schedule
- Delay Watering up to 14 days and automatically resume watering after the set delay has elapsed
- Bypass Rain Sensor for any station gives you the ability to customize which stations react to a rain sensor
- Seasonal Adjust by program allows you to easily reduce or increase watering by program
Specs
- Operating Temperature: Up to 149°F (65°C)
- Storage Temperature: -40°F (-40°C) to 150°F (66°C)
- Operating Humidity: 95% max @ 50°F to 120°F (10°C to 49°C) non-condensing environment
Electrical Specifications
- Input required: 120V∿, 60Hz, 0.3A (International models: 230V∿, 50Hz, 0.136A)
- Output: 24V∿, 60Hz, 1.0A (International models: 24V∿, 50-60Hz, 1.0A) for outdoor models, .6A maximum for indoor models.
- Master Valve/Pump Start Relay
- External battery back-up not required. Nonvolatile memory permanently saves the current programming and a 10 year life lithium battery maintains the controllers time and date during power outages
Certifications
- 120V Models: cULus [US and Canada], FCC Part 15b [US], CAN ICES-3(B)/NMB-3(B) [Canada], NOM-001-SCFI-2018 [Mexico]
- 230V Models: CE [European Union], IP24, RCM [Australia and New Zealand], IRAM [Argentina], EAC [Eurasian Economic Union], ICASA [South Africa], CMAC [Moldova], Kvalitet [Serbia], UkrSEPRO [Ukraine]
Dimensions
- Width: 7.92 in. (20.1 cm)
- Height: 7.86 in. (20.0 cm)
- Depth: 3.51 in. (9.0 cm)
- Indoor Only Models (for some international markets): Height: 16.8 cm Width: 16.7 cm Depth: 4 cm
Model Comparison
120VAC
- TM2-4-120V: 4-station 120VAC
- TM2-6-120V: 6-station 120VAC
- TM2-8-120V: 8-station 120VAC
- TM2-12-120V: 12-station 120VAC
230VAC
- TM2-4-230V: 4 Station 230VAC
- TM2-6-230V: 6 Station 230VAC
- TM2-8-230V: 8 Station 230VAC
- TM2-12-230V: 12 Station 230VAC
- TM2I4-230V: 4 Station, Indoor Only
- TM2I6-230V: 6 Station, Indoor Only
- TM2I8-230V: 8 Station, Indoor Only
- TM2I12-230V: 12 Station, Indoor Only
Accessories
- LNKWIFI: LNK2 WiFi Module for remote control and notification via iOS or Android device
- WR2-RFC: Rain + Freeze Combo
- WR2-48: Rain + Freeze Combo with 48-hour hold
- RSD-BEx: Rain sensor w/ latching bracket, extension wire
